Pressure Monitors

A differential pressure monitor, also known as a manometer, ensures the safety of containment areas by measuring a negative or positive pressure differential in that containment space. The dual pressure manometer plays an important role in projects involving hazardous debris management during abatement or remediation activities, promoting safety for both workers and potential bystanders.

The challenge lies in the low typical negative pressure requirement, often just 0.020 inches of water column (WC), making it hard to find sensitive equipment for accurate measurements. Fortunately, Omnitec Design offers a solution with the Omniguard 6 Pressure Recorder. These self-contained devices provide precise monitoring, robust reporting, and alarm features, all while being user-friendly through a straightforward push-button calibration process.

Need help selecting the right model?

OmniGuard 6 Differential Pressure Monitor
Product No. IOG6
Replaces OmniGuard 5
Buy now

OmniGuard 6 is the gold standard in differential pressure monitoring and recording. This user-friendly device features a robust, long-lasting shell, an improved printer, and upgraded software.

Offering precise pressure readings with an extensive history log accessible via the 4.3″ touch screen or USB transfer, the OmniGuard 6 has enhanced WiFi capabilities for stronger signals and extended range.

This product also has built-in cellular capability and two years of cellular service with purchase.

With a wide operating range with tight accuracy, an optional 95-decibel audible alarm will notify workers and bystanders of containment breaches. 4 MB of internal storage will log up to six months of data. A built-in thermal printer eliminates the need for ink ribbons or expensive cartridges.

Additionally, it comes with dual USB ports for easy setup and data transfer, along with a built-in cellular modem and WiFi for 24/7 remote monitoring of the job site.

OmniGuard 6 is the gold standard in differential pressure monitoring and recording. This user-friendly device features a robust, long-lasting shell, an improved printer, and upgraded software.

Offering precise pressure readings with an extensive history log accessible via the 4.3″ touch screen or USB transfer, the OmniGuard 6 has enhanced WiFi capabilities for stronger signals and extended range.

This product also has built-in cellular capability and two years of cellular service with purchase.

With a wide operating range with tight accuracy, an optional 95-decibel audible alarm will notify workers and bystanders of containment breaches. 4 MB of internal storage will log up to six months of data. A built-in thermal printer eliminates the need for ink ribbons or expensive cartridges.

Additionally, it comes with dual USB ports for easy setup and data transfer, along with a built-in cellular modem and WiFi for 24/7 remote monitoring of the job site.

Applications & Environments

  • Construction, abatement, remediation, and restoration job sites that require negative or positive pressure containment with HEPA filtration including abatement of mold, asbestos, and lead
  • Removal of hazardous odors, VOCs, or fumes with activated carbon filter options in manufacturing and industrial facilities
  • Removal of dust and debris in hospital and healthcare settings (following infection control guidelines)
  • Mobile and pop-up patient isolation applications in hospitals

OmniGuard 6 Differential Pressure Monitor Specifications

IOG6
Operating Pressure Range
+/- 0.250 inches Water Column ( +/- 6.35 mm WC, +/- 62.5 Pascals)
Operating Pressure Accuracy
+/- 0.003 inches Water Column or +/- 1% of reading whichever is greater
WiFi
WiFi can email status changes up to four times per hour and the jog log of the last 24 hours once a day. Supports 802.11b/g/n with WEP, WPA, or WPA2.
Pressure Reading Log Rates (Log Rate)
Normal Operation -- Highest and lowest pressure readings are logged and printed at intervals of 5,15, 30 minutes, or OFF
Alarm Condition -- Highest and lowest pressure readings are logged and printed at intervals of 15, 30, 60, or 120 seconds for the first 10 minutes of alarm condition, increasing to 15-minute intervals thereafter
Alarm
2) programmable alarm settings, optional 95db audible alarm, and red-bordered on-screen warning indication alarm condition
Controls
4.3" Color Touchscreen LCD (480 x 272 pixels), red-bordered on-screen warning indicates alarm condition, tutorial screens, battery life icon
Power Requirements
AC Power: 80-240 VAC 50-60Hz 10W (with 6 ft power cord)
Size
9.25" x 7.5" x 4.5"
Weight
9 LBS (4 KG)
Housing
Copolymer polypropylene (shell and handle), Polycarbonate (window), stainless steel (hanging hook)
swipe

Ordering Information

MACHINES
Part number
OmniGuard 6 Differential Pressure Monitor
ACCESSORIES
Part number
Remote Auxiliary Alarm for Omniguard
IOGALARM-001
10 ft External Hose for Omniguard
IOGHOSE1
